Lake Sawyer Hawks logoLake Sawyer Hawks CG Calculator

Simple, visual, and accurate — supports inches/mm and ounces/grams.

RC Plane Drawing

Reference Points (A / B / C / D)

  • A – Tip of spinner or motor shaft
  • B – Center of main landing gear
  • C – CG per the plan (wing location)
  • D – Center of tail wheel or nose wheel (depends on gear type)

Use Instructions

Level the Plane, making sure the horizontal Stab is sitting level.

  • A minimum of 2 scales are needed, if using 3 scales add the 2 weights together and enter that into "Main Gear Weight"
  • Make sure the Airplane is sitting in flight attitude

Main Gear Distance (A → B)

  • Measured from the tip of spinner or motor shaft.
  • To the Main Gear centerline

Nose/Tail Gear Distance (A → D)

  • Measured from the tip of spinner or motor shaft.
  • Same method as above, using tail or nose wheel location.

Target CG Distance (A → C)

  • Measured from spinner tip or motor shaft to the planned CG line.
  • Example: Plan CG is 5 ⅜ in from the wing leading edge.
    Measure from spinner tip or motor shaft to the CG line on the wing.

Fraction to Decimal Converter

Enter a fraction (e.g. 3/8 or 2 1/4) to get a decimal value:

Decimal: —
CG Acceptable Range The range for and aft of the centerline per drawing
Enter values to see results.
